FIFTH-Remove the top regulator board. Re-move the screws holding
the top, center and bottom of the glass run channel and remove
the channel Remove the three screws holding the cam channel to
the lower sash channel. See Fig. 323.
To install a new door glass, the assembly operations are just the reverse of
the above removal Lift the glass straight up and remove from door.
Removing and Installing Front Door Ventilator Assembly
The front door ventilator assembly is to be serviced as a complete
unit. This includes the ventilator frame and regulator with its
rubber channels,
Fig. 324
A slightly torn headlining may be repaired with-out removing the
entire lining. Loosen the lining from under the retainers, unhook
listing from first hook, and cross-stitch the cut or tear. Cement
a patch to the blind side over the stitching, apply cement to both
the lining and the patch, and allow cement to become "tacky" dry
before pressing together. Use trimmers' cement FS-730. By not replacing
the lining on the outer listing hook 3" more slack in the
lining is obtained and the patched lining may be tucked under the
retainer to remove it from view.
Removal and Replacement of Glass
With the new and improved Fisher Bodies used on the 1935 Chevrolet,
the method of removing and replacing glass changes. These operations
are quite simple and can be performed by any Service man, providing
he has the necessary tools and equipment.
Fig. 323
Before we start to explain the mechanics of removing and replacing
glass, let us review what is standard equipment. Safety plate glass
is used in the windshield and draft deflectors and plate or safety
glass is used in lla other windows. Safety glass is furnished for
all windows at a slight additional cost
The following is the mechanical operations necessary to remove
and replace glass.
Removing and Installing Front Door Window To Remove Glass:
FIRST-Remove garnish moulding screws and garnish mouldings.
SEcoND — Remove screws from glass run channel and remove
channel.
THIRD -Remove inside door handle, door regulator handle, no draft
ventilation control handle, and arm rest.
FouRTH —Remove door trim.
|
